XT-G6000B Linear Beam Combustible Gas Detector for Industrial and Commercial Use

Description

The instrument is composed of a laser transceiver, a reflector, a fixed bracket, etc. It uses the principle of laser absorption spectroscopy (TDLAS) to conduct long-distance real-time online monitoring of the methane gas concentration between the laser transceiver and the reflector, and has the functions of signal acquisition, conversion, and transmission.

Features

Ultra-long monitoring range
Only one-side power supply and wiring required
Backstage computer monitoring

Technical Parameters

Product model: XT-6000B
Detection principle: TDLAS
Detection gas: CH4
Detection range: optional range (0~5000)ppm.m; (0~10000)ppm.m
(0~50000)ppm.m; (0~100)%LEL
Sensitivity: 1ppm.m
Response time: 1 second
Effective detection distance: 0~100m, 0~200m,
Working power supply: DC12V~28V
Output signal: RS485 or 4~20mA
Explosion-proof grade: Ex d II C T6 Gb
Protection grade: IP68
Product weight: 3kg
Installation method: wall-mounted or 4” riser installation
Ambient temperature: -40~+65℃
Ambient humidity: (0~90)% RH non-condensing
